Mini-ITX86350-H81
![](upload/2019361252489300.jpg)
![](/upload/image/20190306/20190306120753805380.jpg)
• LGA1150 酷睿4代 i3/i5/i7/奔腾/赛扬处理器
• DDR3/DDR3L 1600MHz内存,最大支持16GB
• 四个英特尔千兆网口
• 2 个 SATA3.0 , 6 个串口
• 2 个 USB3.0 ,6 个 USB2.0接口
• 2 个 Mini PCIe扩展槽(其中一个 可支持 Mini PCIe与mSATA可调)
Processor System |
CPU |
4th Gen.Intel Core i3/i5/i7/Pentium/Celeron |
Socket |
LGA1150 |
|
Chipset |
Intel H81 |
|
BIOS |
AMI |
|
Memory |
Technology |
DDR3/L 1600/1333MHz |
Max. Capacity |
Up to 16GB |
|
Socket |
2 x 204-Pin SO-DIMM |
|
Display |
Controller |
Intel HD Graphics |
Graphics Memory |
Max. 1.7GB share System Memory |
|
VGA |
2 |
|
DVI |
1 |
|
HDMI |
1 |
|
Multiple Display |
2 independent displays |
|
Ethernet |
Controller |
4 x Intel i210-AT GbE |
Audio |
Chipset |
Realtek ALC887 |
WDT |
Programmable Counter from 1~255 Min/Sec. |
|
Storage |
SATA |
2 x SATA3.0 |
mSATA |
1 (Share with Mini PCIe) |
|
I/O |
Serial Port |
6 x RS232(COM1&COM2 Support RS232/422/485) |
USB |
2 x USB3.0, 6 x USB2.0 |
|
GPIO |
4 x In , 4-Out |
|
PS/2 |
1 |
|
PCIe x16 |
1 |
|
Mini PCIe |
1 x Half-Size, 1 x Full-Size (w/mSATA) |
|
Power |
Type |
ATX |
Dimensions |
170mm x 170mm (Mini-ITX) |
|
Environment |
Operation |
-10~60℃/10~90%,non-condensing |
Non-Operation |
-20~80℃/10~90%,non-condensing |
|
Certification |
EMC |
CE / FCC |
