Mini-ITX86551-H110
![](upload/20193610342038963.jpg)
![](/upload/image/20190306/20190306103483708370.jpg)
· 支持LGA1151 英特尔酷睿6代/7代 i3/i5/i7处理器
· 英特尔 H110 晶片組
· 支持最新DDR4-2133内存,最大支持32GB
· VGA/HDMI/LVDS, 支持双显示
· 双英特尔千兆网口
· 内置USB加密狗接口
Processor |
CPU |
6th(SkyLake)/ 7th(Kaby Lake) Intel Core i3/i5/i7/ Pentium/Celeron Processor (Max 65W) |
Type |
LGA1151 |
|
Chipset |
Intel H110 |
|
BIOS |
AMI UEFI |
|
DRAM |
Technology |
DDR4 2133MHz |
Capacity |
Up to 32GB |
|
Socket |
2 x 260-Pin SO-DIMM Slot |
|
Display |
Graphics |
Intel HD Graphics Support DX11.1 & OpenCL 1.2 |
Graphics Memory |
Share System memory up to 1.7GB SDRAM |
|
VGA |
1 , Up to 1920 x 1200@60Hz |
|
HDMI |
1 , Up to 1920 x 1200@60Hz |
|
LVDS |
1, 2-CH 24bit ,Up to 1920 x 1200@60Hz |
|
Mult-Display |
2 Independent displays |
|
LAN |
2 x Intel LAN (i211-AT ) |
|
Audio |
Realtek ALC269Q with MIC/Line-out |
|
Watchdog |
Programmable from 1 to 255 Sec |
|
Storage |
SATA |
2 x SATA3.0 |
mSATA |
1 (Share w/Mini PCIe) |
|
M.2 |
Vertical M.2 B-Key |
|
RAID |
N/A |
|
I/O |
Serial |
6 x RS232 (COM3 w/ RS232/422/485 ) |
LPT |
N/A |
|
USB |
4 x USB3.0 + 5 x USB2.0 |
|
GPIO |
4-In , 4-Out |
|
PS/2 |
1 |
|
TPM |
N/A |
|
Expansion Slot |
PCIe x16 |
1 ( Ver: 3.0) |
Mini PCIe |
1 (Full-Size,(Share w/mSATA) |
|
Power |
Type |
ATX |
Form Factor |
170mm x 170mm (Mini-ITX ) |
|
Environment |
Operating Temp & Humidity |
-10~70℃/10~90%, Non-condensing |
Storage Temp & Humidity |
-20~80℃/10~90%,Non-condensing |
|
Certification |
EMC |
CE / FCC |
O.S |
Skylake: Windows 7 32/64-Bit Windows 8.1 64-Bit/Windows 2008 R2/Linux (Kernel 3.0+) KabyLake: Windows 10 64bit/Linux (Kernel 4.X) |
